662004231822
Manufacturer:
Wurth Electronics
Mfr.Part #:
662004231822
Datasheet:
Description:
Headers and Wire Housings SMD/SMT Male Pin, Socket Number of Positions:4 Pitch:2.9972 mm
| Parameter | Value |
|---|---|
| Length | 11.4 mm |
| Width | 9.7 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Height | 9.9 mm |
| Packaging | Tray |
| RoHS | Compliant |
| Lead Pitch | 3 mm |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Copper |
| Pitch | 2.9972 mm |
| Current Rating | 5 A |
| Orientation | Vertical |
| Operating Supply Voltage | 250 V |
| Color | Black |
| Gender | Male |
| Number of Contacts | 4 |
| Connector Type | Male Pin, Socket |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Row Spacing | 2.9972 mm |
| Housing Material | Nylon |
| Fastening Type | Ramp |
| Contact Resistance | 10 mΩ |
| Contact Gender | Male |
Stock: 532
Distributors
pcbx
pcbxUnit Price$0.72555
Ext.Price$0.72555
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.72555 | $0.72555 |
| 10 | $0.71141 | $7.11410 |
| 25 | $0.68346 | $17.08650 |
| 50 | $0.65660 | $32.83000 |
| 100 | $0.57439 | $57.43900 |
| 300 | $0.55375 | $166.12500 |
| 500 | $0.53384 | $266.92000 |
